Cisco ASA 5505  |
Cisco ASA 5510  |
Cisco ASA 5520  |
Cisco ASA 5540  |
Cisco ASA 5550  |
|
|---|---|---|---|---|---|
| Target Market | Teleworker/ Branch Office/ SMB | SMB and SME5 | Enterprise | Medium Enterprise | Large Enterprise |
| List Price | Starting at $595 | Starting at $3,495 | Starting at $7,995 | Starting at $16,995 | Starting at $19,995 |
| Performance Max Firewall Max Firewall + IPS Max IP Sec VPN Max IP Sec/SSL VPN Peers |
150 Mbps 45Mbps 100Mbps 25/25 |
300 Mbps 150/300 170Mbps 250/250 |
450 Mbps 350/450 225Mbps 750/500 |
650 Mbps 65Mbps 325Mbps 5000/2500 |
1.2 Gbps N/A 425 Mbps 5000/500 |
| Max Firewall Conns Max Conns/Second Packets/Second (64 byte) Base I/O VLANs Supported HA Supported |
10,000/25,000 3,000 85,000 8-port FE switch 3/20(trunk) Stateless A/S (Sec Plus) |
50,000/130,000 6,000 190,000 5 FE 50/100 A/A and A/S (Sec Plus) |
280,000 9,000 320,000 4 GE + 1 FE 150 A/A and A/S |
400,000 20,000 500,000 4 GE + 1 FE 200 A/A and A/S |
650,000 28,000 600,000 8 GE + 1 FE 250 A/A and A/S |
